What is the difference between fiberglass aluminum foil tape and aluminum foil tape?



What is the difference between fiberglass aluminum foil tape and aluminum foil tape? 01 Process ingredients Glass fiber aluminum foil cloth tape adopts a unique advanced composite …

What is the difference between fiberglass aluminum foil tape and aluminum foil tape?

01

Process ingredients

Glass fiber aluminum foil cloth tape adopts a unique advanced composite process and uses special adhesives to form a dense film, which is composited with aluminum foil. It has a smooth surface, high light reflectivity, high longitudinal and transverse tensile strength, is airtight and watertight, and has good sealing performance. .

Fiberglass aluminum foil cloth is suitable for moisture-proof, mildew-proof and anti-corrosion packaging materials for export equipment. At the same time, aluminum foil cloth is also used to protect and wrap chemical equipment such as petroleum pipelines and steam pipelines, playing the role of flame retardant, anti-corrosion and heat insulation.

Aluminum foil tape uses high-quality pressure-sensitive adhesive, which has good viscosity, strong adhesion, anti-aging and other functions, and its thermal insulation performance is greatly improved. Aluminum foil tape is used to seal punctures on the surface of objects and repair damaged areas. It is the main raw and auxiliary material for refrigerators and freezer manufacturers.

640.  jpg

02

main difference

▲ Glass fiber aluminum foil cloth tape is made of fiberglass aluminum foil cloth cut and rolled according to the width. The base layer used is fiberglass fireproof cloth with a fire protection grade of A. After heating high-viscosity high-temperature glue in a high-temperature environment, the aluminum foil is Laminated to the surface layer of fiberglass fireproof cloth, the use temperature (without contact with open flame) can reach 300-600 degrees. Within a certain range, as the temperature increases, the adhesion performance of fiberglass aluminum foil cloth tape becomes better. This is the reason why aluminum foil Tape doesn’t compare.

▲ Glass fiber aluminum foil tape has high tear resistance and can withstand a certain tearing force, while aluminum foil tape is easier to break.

▲ Glass fiber aluminum foil tape has a wide range of uses and can be used as sealing equipment materials in high temperature environments.

03

Main features of fiberglass aluminum foil tape

1. The surface of aluminum foil is smooth and flat, with high light reflectivity, high longitudinal and transverse tensile strength, airtight, watertight, good sealing performance and strong weather resistance;

2. Glass fiber aluminum foil cloth can effectively shield the electronic interference generated by electronic products and equipment, and is also a suitable material to replace conductive cloth;

3. Fiberglass aluminum foil cloth is composed of aluminum foil conductive cloth and hot melt. It has the characteristics of high shielding rate, strong material toughness and low price.

640.  png

04

Fiberglass aluminum foil tape regular size

1. Thickness: 0.1mm-3.0mm

2. Width: 1m, 1.2m, 1.27m, 1.5m

3. Length: 50m, 100m, 200m, 400m,

4. Color: silver gray surface layer, white or beige base fabric

5. Packaging: Rolled

640 (1).png

05

About fiberglass fireproof cloth base cloth

The base layer of the fiberglass aluminum foil tape is fiberglass fireproof cloth, which is made of six kinds of ores such as pyrophyllite, quartz sand, limestone, dolomite, boronite and boronite as raw materials through high-temperature melting, drawing, winding, weaving, etc. Made by advanced technology, fiberglass fireproof cloth is usually used in fields such as reinforcing materials in composite materials, flame-resistant fireproof materials and thermal insulation materials.
